High Speed Sleeve Seaming Machine
High Speed Sleeve Seaming Machine
This machine is suitable for heat shrinkable film PVC, PET, with the palms in the middle. It is an ideal equipment for producing cold drink labels, mineral water labels, beverage label sleeves, and other packaging.
Product Details
High Speed Plastic PET PVC Sleeve Seaming Making Machine
Performance and Features
1)Stable and heavy-duty frame for high speed operation of 300m/min.
2) Adjustable forming plate creates efficient operation.
3) Auto solvent feeding control.
4) Auto tension control for unwind/rewind unit to maintain the optimun tension.
5) Good brand EPC device, precision 0.1mm.
6) Accurate product width.
7) Cantilevered rewind/unwind shaft for fast roll changeover.
8) PLC with color touch screen control system.
9) Copper tubing with felted wool for gluing, work with glue pump (dispenser) and PLC. The PLC can control the glue capacity with speed changes.
10) Rewind oscillation control to produce high quality rolls.
11) Static eliminator is adopted before rewinder.
12) Whole machine with 4 pcs of servo motors(2 for pulling roller, 1 for rewinder, 1 for oscillation), and 1pc magnetic powder brake for unwinder.
13) Linear perforation.
14) auto stop when the rolls finish.
Technical parameters
Model | 300mm |
Width of Unwinding | 620mm |
Diameter of Unwinding | Ø600mm |
Diameter of Rewinding | Ø700mm |
Min.width of rewinding size | 50mm |
Oscillation width | 0-20mm |
Max. Sealing size | 300mm |
Max Wopeed | 300m/min |
Voltage of Whole Machine | 220V/1phase/ 60hz |
Dimension of Whole Machine | 3000x1600x1720mm |
Weight | 1400kgs |
Standard configurations
Optional parts
Company Introduction
FAQ
1. Q: How does your factory do regarding quality control?
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems. The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.
3. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
